LED Light Pod Amber Lens Each Squadron R Pro Baja Designs

Overview
Specifications
Contact Us

Similar to the Squadron Sport, the Squadron-R Sport off-road lights produce 2,260 lumens of pure power to light up the trail on your nighttime off-roading excursions! The Squadron-R Sport has been designed for customers looking for LED performance with more traditional styling. The Squadron-R Sport has also been optimized for aftermarket bumpers featuring a 4 inch round hole. Enjoy nearly 50,000 hours of optimal performance out of this small, but high-performing auxiliary LED light. As always, Baja Designs offers a 30 Day Satisfaction Guarantee and Limited Lifetime Warranty.
Light Pattern: Wide Cornering: BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 42 degree flattened horizontal beam for the ultimate in comfort lighting.(Lighting Zones 1 and 2)
Baja Designs Features:

Satisfactions Guarantee 30 Day Money Back
Guarantee
Limited Lifetime Warranty Complete Purchase Protection
uService Replaceable Lenses And Optics
ClearView All The Light, Right Where You Need It.
MoistureBlock Waterproof, Rain Proof, Submersible
CopperDrive Only LED Driven At 100 percent
5000K Daylight Less Driver Fatigue, Natural Color

Specifications:

Lumens: 2260 Utilizing 4 Cree High Intensity LEDs
Wattage/Amps:20W/1..4A
Dimensions: 3.07 x 2.77 x 3.5 inch
Weight: 12 ounces
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Powder Coated Cast Aluminum
Bezel: Billet Machined Aluminum
Hardware and Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof, Submersible to 9ft)
IK10 Compliant (Mechanical Impact Testing)

Includes:
Squadron Sport LED Light
Mounting Bracket

Products specifications

Country of Origin	USA
Sold As	Each
UPC	819314021812
Availability	Available
Universal	Yes
Bezel Material	Billet Machined Aluminum
Bracket Material	Stainless Steel
Brackets Included	Yes
Housing Type	Hard Anodized and Powder Coated Cast Aluminum
IK10 Compliant	IK10 Compliant (Mechanical Impact Testing)
Lens Color	Amber
Lens Material	Hard Coated Polycarbonate
Life Span Expectancy	49,930 Hours
Light Pattern	Wide Cornering
Mfg Label	LED Light Pods
Waterproof Rating	IP69K Waterproof
Wattage/AMP	42W/ 3.5A
Youtube Video	https://youtu.be/G9rvxf9ZF8M
Series	Squadron R Pro Series
Lumens	4,900
Color	Black
Proposition 65 Warnings	CALIFORNIA WARNING: Cancer and Reproductive Harm -www.P65Warnings.ca.gov
