6 XL Linkable Light Bar Kit 21-Up Ford Bronco Steel Bumper Mount w/Upfitter Baja Desgins

Manufacturer: Baja Designs

SKU: 447750UP-FGXX

Manufacturer part number: 447750UP

Be the first to review this product

$1,538.95

Qty:

+ -

Vehicle Fitments

Make	Model	Submdel	From	To
Ford	Bronco	Badlands	2021	2021
Ford	Bronco		2021	2021
Ford	Bronco	Big Bend	2021	2021
Ford	Bronco	Black Diamond	2021	2021
Ford	Bronco	First Edition	2021	2021
Ford	Bronco	Outer Banks	2021	2021
Ford	Bronco	Wildtrak	2021	2021

Overview
Specifications
Reviews
Contact Us

Full adjusent. Total Performance. The XL Linkable was designed for the enthusiast looking to take charge with a light package that is completely customizable for their needs.

This kit includes 5 XL Sports, Links, vehicle specific mounting brackets, wiring harness and rock guards. A pre-load support bracket is included to ensure stiffness in the most extreme terrain.

This kit is a turn key LED system for the Ford Bronco owner that is looking to drastically improve the looks and performance of their truck.

Please Note: This lightbar may interfere with a portion of the viewing window in front facing camera equipped vehicles.

Baja Designs Features:

Satisfactions Guarantee - 30 Day Money Back Guarantee
Limited Lifetime Warranty - Complete Purchase Protection
uService - Replaceable Lenses And Optics
ClearView - All The Light, Right Where You Need It.
MoistureBlock - Waterproof, Rain Proof, Submersible
CopperDrive - Only LED Driven At 100 percent
5000K Daylight - Less Driver Fatigue, Natural Color

Specifications:

Lumens: 18,900 Utilizing 24 LEDs
Wattage/Amps: 156W / 12A
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Powder Coated Cast Aluminum
Bezel: Billet Machined Aluminum
Hardware and Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof, Submersible to 9ft)
IK10 Compliant (Mechanical Impact Testing)

Includes:

x2 XL Sport Spot LED Light
x2 XL Sport Driving/Combo LED Light
x2 XL Sport Wide Cornering LED Light
x6 XL Sport Rock Guards
Upfitter Style Wiring Harness
Vehicle Specific Mounts

Application:

2021 - On Ford Bronco w/ Steel Bumper

Adjustability:

Patterns:

Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Driving (44 Degree) and spot (6 Degree) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)

Wide Cornering: BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 44 Degree flattened horizontal beam for the ultimate in comfort lighting. (Lighting Zones 1 and 2)

High Speed Spot: A longer and narrower 6 Degree beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights. (Lighting Zone 4 and 5)

Products specifications

Country of Origin	USA
Sold As	Kit
UPC	810031743964
Availability	Available
Universal	No
Bezel Material	Billet Machined Aluminum
Bracket Material	Stainless Steel
Brackets Included	Yes
IK10 Compliant	IK10 Compliant (Mechanical Impact Testing)
Life Span Expectancy	49,930 Hours
Waterproof Rating	IP69K (Waterproof up to 9ft Pressure Washable)
Series	XL Series
Color	Black
Proposition 65 Warnings	CALIFORNIA WARNING: Cancer and Reproductive Harm -www.P65Warnings.ca.gov
